Trek Fuel EXe 5 2025
Product Details
Brand: Trek
UPC: 768682648360
Fuel EXe 5 is an aluminum electric mountain bike that brings all the tech of its carbon counterpart into a pocket-friendly package. It boasts the same tiny-but-mighty drive system that quietly disappears under you, plus a sleek display and remote. But what really makes this bike excel is its true trail bike feel that handles just like a traditional mountain bike, just with a little extra power.
| Frame | Alpha Platinum Aluminum, removable battery, internal routing, alloy rocker link, 34.9mm seat tube, upper chain guide mount, 55mm chainline, Mino Link, ABP, Boost148, UDH, 140mm travel |
|---|---|
| Fork | RockShox Recon Silver, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, 150mm travel |
| Shock | X-Fusion Pro 2, 2-position damper, 205mm x 60mm |
| Max compatible fork travel | 160mm (575mm axle-to-crown) |
Wheels
| Hub front | Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle |
|---|---|
| Hub rear | Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Rim | Bontrager Line TLR 30, Tubeless Ready, 32-hole, Presta valve |
| Tire | Bontrager XT3 Elite, wire bead, 60 tpi, 29x2.40" |
| Rim strip | Bontrager TLR |
| Max tire size | Frame: 29x2.50", Fork: See manufacturer |
Drivetrain
| Shifter | Shimano Deore M6100, 12 speed |
|---|---|
| Rear derailleur | Shimano Deore M6100, long cage |
| Crank | E*thirteen E*spec Plus, 165mm length |
| Chain ring | E*thirteen E*spec, 32T alloy ring, 55mm chainline |
| Cassette | Shimano Deore M6100, 10-51, 12 speed |
| Chain | Shimano Deore M6100, 12 speed |
| Max chainring size | 1x: 34T, min 30T |
Components
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
|---|---|
| *Seatpost | Size: S TranzX JD-YSI-22PLQ, 100mm travel, internal routing, 34.9mm, 346mm length |
| Size: M TranzX JD-YSI-22PLQ, 150mm travel, internal routing, 34.9mm, 454mm length |
|
| Size: L, XL TranzX JD-YSI-22PLQ, 170mm travel, internal routing, 34.9mm, 497mm length |
|
| Handlebar | Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width |
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| Stem | Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length |
| Headset | Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible |
| Brake | Tektro HD-M745 hydraulic disc |
| Brake rotor | Tektro, 6-bolt, 203mm |
| Rotor size | Max brake rotor sizes - Frame: 203mm, Fork: see fork manufacturer |
Accessories
| Battery | TQ 360Wh |
|---|---|
| Motor | TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power |
| Computer | TQ LED display with Bluetooth & ANT+ connectivity |
| Electronics | TQ 4A charger |
Weight
| Weight | M - 20.80 kg / 45.86 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
